TM-S850 Cutting plotter

TM-S850 Cutting plotter
Basic Parameters:

Advantage:high precision, high speed, go paper not offset, the most stable performance

Applicable industry:
Stickers, note posted, mobile phone film, 3 m reflective film, etc.
Application materials:
Advertising, electronics, traffic signs, clothing drawing

Product Features:
1,The machine body is made of aero aluminum alloy ,enable it to work stably under high speed
2, Appearance generous, structure more scientific。
3,Super wide aluminum stents, machine move more stablely
4,imported spinous feed roller makes the media feed stably ,long service time.
5,Cutter head is made of metal,strong and durable blade force,and adjust precision,the blade force can be reach 1000mm
6,DSP processors, fast operation low noise, can be directly output by U plate;
7,The high quantity in both English and Chinese LCD backlight shows independent switch
8,Built-in closed compensation ,cusp compensation can be directly compatible with Coreldraw, CAD and other software output cut
Product Parameters:
Item TM-S850
Max feeding width 850mm
Max engraving width 750mm
Speed 1000mm/s
Blade pressure 10~500g
Memory 512kto1M
Mechanical resolution 0.0254mm/step
Repeatability 0.127mm
Interface RS-232 USB
Language format DM/PL/HPGL
Power AC160V~240V 50~60HZ
Services:
1 FREE for users to provide relevant technical guidance and advice; according to the user equipment and requirements for use of the environment to provide relevant recommendations;
2 FREE delivery device (freight delivery shall bear responsibility for the customer is responsible for pick-unloading charges customers themselves);
3 FREE onsite installation and commissioning services;
4 FREE training of personnel;
5 YEAR warranty expires, the warranty period, only charge labor and parts costs; guaranteed lifelong service.
