LED UV FB3368

Basic Parameters：

PRODUCT ID： FB3368

PRODUCT NAME： LED UV FB3368

Specification：

PRODUCT NOTES：

1.High Stability

2.White Ink Available

3.High Fastness Image.

4.White ink won’t block the print head.

5.High Resolution: Min Font 0.1mm;

Product Features：

Embossed Image

Image printed by the FB3368 uv flatbed

printer is embossed on the surface so

that it can give you product more added

value. And it has already helped many

phonecover makers, gift producer and

advertising companies earn times of

money.

High Resolution & White Ink Print

High Resolution Min Font 0.1mm

No Striation on & Accurate Position

No matter how thick you print white ink, there isn’t any striation on the

surface. As a result, the image is always of good effect, and the product

will be distinguished from that with bad printing.

Accurate Position:

The UV flatbed printer adopts good lead screw to produce good and vivid

images no matter how many times the print repeated.

Wide Application:

The UV flatbed printer is widely used to print phone covers, acrylic

nameplate,gift box,notebook cover, glass, business card holder, etc.

Product Parameters：

Technical Parameters:

FB3368 UV Flatbed Printer
Print size			60cm*150cm
Print Head			Piezo-electro 1440 Nozles
Print Color			C, M, Y, K, W, Clear Varnish
Print Direction			Bi-direction
Print Speed			A4(1440DPI)/3Mins
Max Media Thickness			12cm
Max Media Weight			25kgs
Max Resolution			2880dpi*1440dpi
Ink System			220ml
Ink			Eco UV Ink
Height Adjusting			Auto/Manual
Material Height Detection			Induction
Print head Protection			Auto_touch Induction
Power			110-220v; 50-60HZ; 78W
Interface			USB 2.0/IEEE1394
Computer System			Windows95, 98, NT, 2000, XP, 2003/MAC/Linus
Working Condition	Temperature		10-35°C
	Relative Humidity		20-80%
Gross Weight/Net Weight			240kgs/210kgs
Printer Size			274cm132cm113cm
Shipping Size			284cm142cm130cm
UV Light		Number of UV Lights	2 UV Lights
		Duty	40W
		Lifespan	25000hrs
Software			Special RIP Software

Services：

1 FREE for users to provide relevant technical guidance and advice; according to the user equipment and requirements for use of the environment to provide relevant recommendations;
2 FREE delivery device (freight delivery shall bear responsibility for the customer is responsible for pick-unloading charges customers themselves);
3 FREE onsite installation and commissioning services;
4 FREE training of personnel;
5 YEAR warranty expires, the warranty period, only charge labor and parts costs; guaranteed lifelong service.
