TM-3226C CNC Router

Basic Parameters：

Applicable industry：
Electronic fixture, power distribution cabinet, glasses industry, handicraft processing, advertising, seal industry. Such as: instrument processing, metal plate, hot stamping plate, the atomic chapter, battery carbon plate, copper chapter, small technology element cutting, etc.
Application materials：
Acrylic,PVC board,soft and hard wood,plywood,MDF,ABS double color sheet ,Electric board, aluminum, copper, iron, etc.

Product Features：

1.Whole machine casting: machine overall structure using cast iron parts, rigid, smooth operation, little vibration machine overall.
2.High intelligence operation：Adopt unique intelligent calculation to realize high speed processing, curve and linear synchronous, curve more smooth;
3.Worktable can move:Y axis can move , high precision engraving
4.Arbitrary switching workpiece coordinates：Can store 9 coordinates zero point,working coordinates can be switch arbitrary
5.USB offline control：The USB interface communication with the computer, instantly complete data transmission；
6.Continuous engraving function：It is able to go on engraving and cutting when the electricity is cut or the tool is broken ,convenient and easy operate.
7.Import screw guide：Excellent two-bolt pole made in germany and import slidway
8.High power driver device:capability is strong, the noise is small, it is stable and reliable
9.Lower failure rate：Internel line shielded perfect,anti-interference,high signal,lower failure rate
10.Strong compatibility：compatible with,Type3/Artcam/Castmate/Proe/UG/ lasercut and all kinds of CAD/CAM software.

Product Parameters：

Table size	550x600x525mm
Working size	320x260x80mm
Z axis height	80mm
Max engraving speed	4500mm/min
Min feeding speed	1mm
XYZ Resolution	0.0125mm
Instruction format	HPGL or G code
Spindle speed	6000-24000rpm/min
Spindle tool	￠3.175/￠6mm
Power	AC220/50HZ
Power consumption	500W（void load）
Weight	150kg

Services：

1 FREE for users to provide relevant technical guidance and advice; according to the user equipment and requirements for use of the environment to provide relevant recommendations;
2 FREE delivery device (freight delivery shall bear responsibility for the customer is responsible for pick-unloading charges customers themselves);
3 FREE onsite installation and commissioning services;
4 FREE training of personnel;
5 YEAR warranty expires, the warranty period, only charge labor and parts costs; guaranteed lifelong service.
